Reference Designs for Xilinx® FPGAs

OmniOn Power is an approved power partner for Xilinx® FPGAs. We work closely with Xilinx® to develop proven power solutions for Xilinx® FPGA applications. OmniOn Power power modules can be used across all Xilinx® FPGA and SoC product families and for the newest Xilinx® 16nm Ultrascale+™ FPGAs, helpful reference designs are provided on this site.

Our comprehensive family of voltage regulators/power modules (POLs) meets the stringent FPGA voltage requirements for power rails from 2A to over 300A with high efficiency and excellent thermal derating. Our compact and fully integrated DLynx* and (opens in a new window)DLynx II* converters deliver tight voltage regulation, fast transient response, accurate PMBus telemetry and programmability, robust protection features and power sequencing required for advanced FPGA power designs.

Agency proven reliability (IPC-9592) and use of digital design tools like (opens in a new window)Power Module Wizard and (opens in a new window)Digital Power Insight help make powering Xilinx® FPGAs with DLynx and DLynx II power modules easier for power designers.

Learn More About Our OmniOn Power Integrated Power Solutions for Xilinx® FPGA's:

• Virtex Ultrascale+™ / OmniOn Power PoL Module Selection Chart
• Kintex Ultrascale+™ / OmniOn Power PoL Module Selection Chart
