— — DLynx III

The digital DLynx III™ power modules are easy to use, highly configurable non-isolated DC-DC converters that can deliver from 15A up to 320A of output current in both stand-alone and master/satellite configurations.

The MLX/SLX-series operates over a wide input voltage range from 7 VDC to 14 VDC, providing PMBus™-programmable output voltages from 0.45 VDC to 2.0 VDC. With the MLX and SLX DC/DC converters, master modules can either operate as standalone modules or be paired with SLX satellite modules to deliver increased maximum output current for a single output or to provide a second independent, digitally controlled output to power multiple loads.

The FPLX-series extends the product family with stand-alone 15A, 20A, and 30A modules that are available in compact, 10mm x 10mm common footprints – providing flexibility for applications requiring lower power ranges. The FPLX modules also provide wide input and output voltage ranges, making them well suited for a broad range of applications.

Benefits

Minimized Board Space Requirements

High-density footprint, 97 to 205 A/in², depending on module.

High Efficiency across Applications.

88-90% efficiency at full load (12 VIN, 1 VOUT, at 25°C) depending on module.
Increased efficiency at low-load operation with user-selectable phase shedding in MLX series and diode emulation mode in FPLX series

Long-Term Reliability

Excellent thermal performance: DLynx III modules provide maximum rated current for 12VIN, 1VOUT at 200lfm airflow and ambient temperatures of 80°C or better.
Compliant to IPC9592 Category 2 Class 2 power conversion device requirements.
Voltage, current and temperature protections to help guard systems and modules from excessive or dangerous conditions.

Simplified Solution Design with Rich Digital Features

Broad temperature operating range: -40°C to 85°C.
Common pinout of FPLX series and nested pinout of MLX modules provides design flexibility.
Convenient and powerful digital control and monitoring with PMBus.
Design support with Digital Power Insights software.
Cloud-based Power Module Wizard tool enables efficiency, transient and ripple simulations, and helps in the module selection process.

Cost-efficient, open-frame design

Applications

Telecommunications and networking equipment
Workstations, servers, and storage
Test and measurement equipment
Industrial equipment
Distributed power architectures
Broad range of embedded applications
High-current ASIC/SoC power
Networking processor power
High-current FPGA power
High-performance ARM processor power

Power Modules	Communications	Input Range	Vout	Iout	PEAK EFFICIENCY	ECAD MODEL	Check Inventory	power module wizard
FPLX015 Documents (opens in a new window) FPLX015_DS, Data Sheets (opens in a new window) FPLX Eval Board_AN, Application Notes (No Documents Available) (No Documents Available)	PMBus	6 – 14V	0.45 – 3.6V	15A	94%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
FPLX020 Documents (opens in a new window) FPLX020_DS, Data Sheets (opens in a new window) FPLX Eval Board_AN, Application Notes (No Documents Available) (No Documents Available)	PMBus	6 – 14V	0.45 – 3.6V	20A	94%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
FPLX030 Documents (opens in a new window) FPLX030_DS, Data Sheets (opens in a new window) FPLX Eval Board_AN, Application Notes (No Documents Available) (No Documents Available)	PMBus	6 – 14V	0.45 – 2.0V	30A	92%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
MLX040 Documents (opens in a new window) MLX-SLX PMBus Commands_AN, Application Notes (opens in a new window) MLX-SLX Advanced Features_AN, Application Notes (opens in a new window) MLX040_DS, Data Sheets (opens in a new window) Reliability Considerations Comparing POL Module to Discrete Implementation, Application Notes (opens in a new window) Filtering and Layout Guidelines for POL_AN, Application Notes (opens in a new window) MLX-SLX Dual Output Eval Board_AN, Application Notes (opens in a new window) MLX-SLX Single Output Eval Board_AN, Application Notes (opens in a new window) MLX Eval Board_AN, Application Notes (opens in a new window) UL_NOA_MLX_SERIES (opens in a new window) VDE_CERTIFICATE_MLX (opens in a new window) EU RoHSIII_MLX040A0XY3-SRZ (opens in a new window) REACH_SVHC-240_MLX040A0XYxxx Series	PMBus	7 – 14V	0.45 – 2.0V	40A	96%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
MLX080 Documents (opens in a new window) MLX-SLX PMBus Commands_AN, Application Notes (opens in a new window) MLX-SLX Advanced Features_AN, Application Notes (opens in a new window) MLX080_DS, Data Sheets (opens in a new window) Reliability Considerations Comparing POL Module to Discrete Implementation, Application Notes (opens in a new window) Filtering and Layout Guidelines for POL_AN, Application Notes (opens in a new window) MLX-SLX Dual Output Eval Board_AN, Application Notes (opens in a new window) MLX-SLX Single Output Eval Board_AN, Application Notes (opens in a new window) MLX Eval Board_AN, Application Notes (opens in a new window) UL_NOA_MLX_SERIES (opens in a new window) VDE_CERTIFICATE_MLX (opens in a new window) EU RoHSIII_MLX080A0XY3-SRZ (opens in a new window) REACH_SVHC-240_MLX080A0XYxxx Series	PMBus	7 – 14V	0.45 – 2.0V	80A	96%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
MLX120 Documents (opens in a new window) MLX-SLX PMBus Commands_AN, Application Notes (opens in a new window) MLX-SLX Advanced Features_AN, Application Notes (opens in a new window) MLX120_DS, Data Sheets (opens in a new window) Reliability Considerations Comparing POL Module to Discrete Implementation, Application Notes (opens in a new window) Filtering and Layout Guidelines for POL_AN, Application Notes (opens in a new window) MLX-SLX Dual Output Eval Board_AN, Application Notes (opens in a new window) MLX-SLX Single Output Eval Board_AN, Application Notes (opens in a new window) UL_NOA_MLX_SERIES (opens in a new window) VDE_CERTIFICATE_MLX (opens in a new window) EU RoHSIII_MLX120A0XY3-SRZ (opens in a new window) REACH_SVHC-240_MLX120A0XYxxx Series	PMBus	7 – 14V	0.45 – 2.0V	120A	96%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
MLX160 Documents (opens in a new window) MLX-SLX PMBus Commands_AN, Application Notes (opens in a new window) MLX-SLX Advanced Features_AN, Application Notes (opens in a new window) MLX160_DS, Data Sheets (opens in a new window) Reliability Considerations Comparing POL Module to Discrete Implementation, Application Notes (opens in a new window) Filtering and Layout Guidelines for POL_AN, Application Notes (opens in a new window) MLX-SLX Dual Output Eval Board_AN, Application Notes (opens in a new window) MLX-SLX Single Output Eval Board_AN, Application Notes (opens in a new window) MLX Eval Board_AN, Application Notes (opens in a new window) UL_NOA_MLX_SERIES (opens in a new window) VDE_CERTIFICATE_MLX (opens in a new window) EU RoHSIII_MLX160A0XY3-SRZ (opens in a new window) REACH_SVHC-240_MLX160A0XYxxx Series (opens in a new window) EU RoHSIII_1600308028A NEXTGEN POL PROTOTYPE 160A	PMBus	7 – 14V	0.45 – 2.0V	160A	96%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
SLX040 Documents (opens in a new window) MLX-SLX PMBus Commands_AN, Application Notes (opens in a new window) MLX-SLX Advanced Features_AN, Application Notes (opens in a new window) SLX040_DS, Data Sheets (opens in a new window) Reliability Considerations Comparing POL Module to Discrete Implementation, Application Notes (opens in a new window) Filtering and Layout Guidelines for POL_AN, Application Notes (opens in a new window) MLX-SLX Dual Output Eval Board_AN, Application Notes (opens in a new window) MLX-SLX Single Output Eval Board_AN, Application Notes (opens in a new window) UL_NOA_SLX160_040 (opens in a new window) VDE_CERTIFICATE_MLX (No Documents Available)	PMBus	7 – 14V	0.45 – 2.0V	40A	96%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
SLX160 Documents (opens in a new window) MLX-SLX PMBus Commands_AN, Application Notes (opens in a new window) SLX160_DS, Data Sheets (opens in a new window) MLX-SLX Advanced Features_AN, Application Notes (opens in a new window) Reliability Considerations Comparing POL Module to Discrete Implementation, Application Notes (opens in a new window) Filtering and Layout Guidelines for POL_AN, Application Notes (opens in a new window) MLX-SLX Dual Output Eval Board_AN, Application Notes (opens in a new window) MLX-SLX Single Output Eval Board_AN, Application Notes (opens in a new window) UL_NOA_SLX160_040 (opens in a new window) VDE_CERTIFICATE_MLX (opens in a new window) EU RoHSIII_1600308028A NEXTGEN POL PROTOTYPE 160A	PMBus	7 – 14V	0.45 – 2.0V	160A	96%	PCB Symbol, Footprint & 3D Model	Check stock (opens in a new window)	Use the Tool (opens in a new window)
